Orlando International (MCO) Schedules API

You need reliable arrivals and departures for Orlando International Airport (IATA: MCO) that your app can query and cache. By the end of this guide you’ll call the FlightLabs schedules endpoint for MCO, parse the JSON for times and terminals, understand when to switch to real-time status, and design polling and caching that won’t spam your users or your quota.

What “schedules at MCO” actually means

Flight schedules are timetables: planned departure and arrival times, plus basic route and aircraft context. They answer “what’s expected at MCO and when.” They typically do not contain gate changes, rolling delays, or cancellations. For those events, combine schedules with real-time tracking.

With FlightLabs you’ll mainly use:

• Schedules: GET /flights-schedules?iataCode=MCO&type=arrival or departure
• Real-time tracking and status: the real-time category, for gates, delays, and in-flight updates
• Future planning: future flights for longer-range planning when a standard schedule is insufficient
• History: flights-history for post-day QA and analytics

All data is returned as JSON from a simple REST interface. You authenticate with an API key from Register.

Choosing the right endpoint for an MCO use case

For Orlando International Airport (MCO), start with the schedules endpoint to populate baseline airport boards and daily manifests. As the time window narrows (for example, within a few hours of departure or arrival), augment rows with real-time status for delays, gates, and diversions.

Endpoint basics for MCO schedules

The schedules endpoint is available under the FlightLabs Scheduling and Planning category. For MCO, set iataCode=MCO and choose type=arrival or type=departure to scope the direction. If you need longer-range or filters beyond these parameters, pair the schedules endpoint with the Future Flights endpoint or consult the Documentation for date windows and pagination options.

• Base URL: https://api.goflightlabs.com
• Schedules path: /flights-schedules
• Required query params shown: iataCode, type

Copy-paste curl: MCO departures schedule

This request retrieves scheduled departures for Orlando International (MCO). Replace YOUR_API_KEY with your FlightLabs key.

curl -G "https://api.goflightlabs.com/flights-schedules" \
--data-urlencode "api_key=YOUR_API_KEY" \
--data-urlencode "iataCode=MCO" \
--data-urlencode "type=departure"

Tip: Cache this response for 15–60 minutes for airport boards and only re-poll near flight time with the real-time endpoint for gates and status.

Parsing schedules: JSON fields you’ll actually use

Below is an official example from the schedules category. While the flight and airports in this example are generic, the structure is representative of what you’ll receive for MCO.

{
"success": true,
"data": {
"schedules": [
{
"flight_number": "UA456",
"departure": {
"airport": "SFO",
"scheduled": "2024-03-20T08:00:00Z",
"terminal": "3"
},
"arrival": {
"airport": "ORD",
"scheduled": "2024-03-20T14:15:00Z",
"terminal": "1"
},
"aircraft": {
"type": "Boeing 787-9",
"registration": "N123UA"
},
"airline": {
"name": "United Airlines",
"iata": "UA"
}
}
]
}
}

What matters for MCO integrations:

• flight_number: Combine with airline.iata to display standardized flight IDs (e.g., UA456).
• departure/arrival.scheduled: UTC timestamps; convert to America/New_York for display at MCO and clearly label the timezone for users.
• departure/arrival.terminal: Terminal identifiers are part of the plan. Gates are not included here; retrieve them from the real-time endpoint when needed.
• airline.iata and airline.name: Useful for grouping rows and rendering logos (assets not provided by this API).
• aircraft.type and registration: Optional display and internal analytics.

Augmenting schedules with live status for MCO

Schedules won’t indicate delays, gate changes, or cancellations. Use the real-time category to get operational status and gate data for flights touching MCO. The official real-time example below shows the kinds of fields you can expect:

{
"success": true,
"data": {
"flight": {
"iata": "AA123",
"icao": "AAL123",
"number": "123",
"status": "en-route",
"departure": {
"airport": "JFK",
"scheduled": "2024-03-20T10:00:00Z",
"actual": "2024-03-20T10:05:00Z",
"terminal": "8",
"gate": "B12"
},
"arrival": {
"airport": "LAX",
"scheduled": "2024-03-20T13:15:00Z",
"estimated": "2024-03-20T13:20:00Z",
"terminal": "4",
"gate": "45A"
},
"position": {
"latitude": 39.8729,
"longitude": -98.7372,
"altitude": 35000,
"speed": 495,
"heading": 270
}
}
}
}

Fields to propagate into your MCO board or notifications:

• status: Use for on-time, delayed, en-route, landed, or cancelled logic in UI.
• departure.actual and arrival.estimated: Override scheduled times when present.
• terminal and gate: Show on the airport display; fall back to scheduled terminal when gate is not available.
• position: Optional for in-flight maps or “X minutes out” features.

When a flight is cancelled or diverted, reflect it as soon as status indicates the change. Retain the scheduled row (with a struck or muted style) so users understand what was planned versus what happened.

JavaScript example: fetch MCO departures and map to a board

This sample calls the schedules endpoint and normalizes the fields you’ll actually show. Replace YOUR_API_KEY with your key.

async function fetchMcoDepartures() {
const params = new URLSearchParams({
api_key: "YOUR_API_KEY",
iataCode: "MCO",
type: "departure"
});
const url = `https://api.goflightlabs.com/flights-schedules?${params}`;

const res = await fetch(url);
if (!res.ok) {
throw new Error(`HTTP ${res.status}`);
}
const json = await res.json();
if (!json.success || !json.data || !Array.isArray(json.data.schedules)) {
throw new Error("Unexpected response shape");
}

// Normalize each schedule row for UI
return json.data.schedules.map(s => ({
flightNumber: s.airline?.iata ? `${s.airline.iata}${s.flight_number}` : s.flight_number,
airlineName: s.airline?.name || "",
depAirport: s.departure?.airport || "",
depScheduledUtc: s.departure?.scheduled || null,
depTerminal: s.departure?.terminal || null,
arrAirport: s.arrival?.airport || "",
arrScheduledUtc: s.arrival?.scheduled || null,
arrTerminal: s.arrival?.terminal || null,
aircraftType: s.aircraft?.type || "",
registration: s.aircraft?.registration || ""
}));
}

// Example usage
fetchMcoDepartures()
.then(rows => {
// Render your board, converting UTC to America/New_York with your TZ library
console.log(rows.slice(0, 3));
})
.catch(err => console.error(err));

Time zones and display at MCO

• All times in samples are ISO-8601 UTC (suffix Z). Convert to the local airport time for users in Orlando (America/New_York) and label clearly (“Scheduled 14:15 EDT”).
• Daylight saving: rely on your time-zone library to avoid manual offsets.
• When mixing schedules and real-time, prefer actual/estimated when present; otherwise fall back to scheduled.

Polling, caching, and error handling

• Caching for schedules: Cache MCO schedules for 15–60 minutes. Refresh more frequently only in the 2–4 hours before departure/arrival as your UX demands.
• Real-time polling: Increase frequency near event (e.g., every 30–90 seconds) to capture gate changes and rolling ETAs. Back off to 3–5 minutes outside the near-term window.
• Graceful degradation: If real-time is temporarily unavailable, keep schedule rows visible and mark status as “check back soon.”
• 404/empty lists: When an endpoint returns no data for the filter, show an empty state with a refresh option, not a crash dialog.

Handling cancellations, diversions, and codeshares

• Cancelled/diverted: The schedules endpoint represents planned operations; detect operational changes via the real-time status field and arrival/departure actual/estimated times.
• Gates and terminals: Terminals in schedules are planned. Gates usually appear in the real-time response and may change; reconcile in your UI by timestamp.
• Codeshares: When codeshare information is present in responses, surface the operating carrier prominently and list marketing flight numbers as alternates. Field names vary; check the Documentation for the specific shapes.

Pagination and date windows for MCO schedules

The sample parameters for schedules show iataCode and type. If you need to constrain by date/time, page through large result sets, or filter by airline or route, consult the schedules section in the Documentation. Implement cursor or page-number iteration in your client so airport views at MCO remain responsive even on peak days.

Operational architecture tips for MCO deployments

• Pre-warm cache: Hydrate the MCO arrivals and departures lists for the next few hours on a schedule. Store minimal normalized records for fast rendering.
• Selective refresh: When a user opens a flight row, fetch the live status to get gate and the latest ETA.
• Edge compute: If you distribute displays across terminals, consider running a small worker that polls and fans out updates via WebSocket or SSE.
• Testing: Use the MCP console to experiment with queries and validate response shapes before shipping.

Airport context: Orlando International (MCO)

Orlando International Airport serves Central Florida with multiple terminals and a broad mix of domestic and international routes. For developers, this means heavy schedule volume and frequent gate activity; design your client to merge schedules with real-time status cleanly and to keep UTC conversions consistent across all views.

Security and API keys

• Keep your FlightLabs API key server-side in production. For client-side apps, proxy requests through your backend and apply rate limiting.
• Rotate keys periodically and separate staging from production keys to avoid data contamination.
• Use structured logging to capture endpoint, parameters, and request IDs for debugging schedule gaps.

Balanced comparison: schedules vs. alternatives for MCO

Within FlightLabs, you have multiple ways to build an MCO board. The table below contrasts the technical trade-offs without benchmarking external providers.

Performance and quotas

Response times and quotas vary by plan and usage. Start with the trial (7 days or 50 requests) and move to the Starter tier at $24.99/month as you integrate more endpoints and scale queries. For detailed limits and recommended usage patterns, review the product pages and Documentation.

Going further: routes and planning around MCO

• Routes: Use the routes category to understand which city pairs commonly touch MCO for broader coverage and pre-fetching.
• Delay predictions: Incorporate the flight-delay category to proactively flag risky connections or staffing surges.
• Airline-specific views: Combine the airline flights category with MCO filters to power branded dashboards.

Quick start checklist for your MCO schedules integration

• Create your API key via Register.
• Call /flights-schedules with iataCode=MCO and type=arrival|departure and cache the results.
• On row expand or within 2–4 hours of departure/arrival, call the real-time endpoint and merge status, gate, and estimated/actual times.
• Render local times with America/New_York, clearly labeled, with UTC available on hover or detail screens.
• Implement backoff and retry for transient errors; log parameters and request IDs.

Reference: Airport information shape

For completeness, here is the official Airport Information example. Use it for enriching your MCO experience with terminals and timezone context where available.

{
"success": true,
"data": {
"airport": {
"iata": "JFK",
"icao": "KJFK",
"name": "John F. Kennedy International Airport",
"location": {
"lat": 40.6413,
"lon": -73.7781,
"city": "New York",
"country": "United States"
},
"timezone": "America\/New_York",
"terminals": [
"1",
"2",
"4",
"5",
"7",
"8"
],
"runways": [
{
"length_ft": 14511,
"width_ft": 150,
"surface": "concrete",
"designator": "13L\/31R"
}
],
"weather": {
"temp_c": 22,
"visibility_km": 10,
"wind": {
"speed_kts": 8,
"direction_deg": 180
}
}
}
}
}

Use timezone to confirm your conversions for MCO (which also uses America/New_York). Terminal lists are useful for validating expected terminal codes in schedules and real-time data.

FAQ

How do I filter schedules to only arrivals at MCO?
Call the schedules endpoint with iataCode=MCO and type=arrival. Cache responses and refresh periodically.

Where do I get gates and delay status for MCO flights?
Use the real-time category. Merge gate, status, actual and estimated times with your schedule rows to keep the board current.

What timezone are times returned in?
Samples show ISO-8601 UTC timestamps (Z). Convert to America/New_York for display at MCO and label the timezone prominently.

How should I handle cancellations?
Schedules represent plans. Detect cancellations via the real-time status field and retain the original scheduled row with a clear cancelled indicator.

Is there a trial and an entry plan?
Yes. A 7-day or 50-request trial is available, and the Starter plan is $24.99/month. See the site and documentation for details.

Get your API key and start shipping an MCO schedules board in minutes. Create your account at Register, then explore endpoints, fields, and examples in the Documentation. You can also test calls in the MCP console.
